SUBWOOFER
GLADEN RS-X 08
- • 8" / 20 cm Subwoofer
- • 375 / 250 Watt
- • 4 Ohm impedance
- • 2" voice coil
Overview RS-X 08
RS-X 08 為 20 公分超低音單體，採用鑄造鋁合金框架、黑色 Nomex 彈波、紙質振膜與 PP 防塵罩，於極小體積中提供令人意外的低頻能量。承襲 SQX 系列的振膜與框架設計理念，可彈性安裝於空間受限的車型，是門板或座椅下安裝的理想選擇。
- ✓ 8 吋 / 20 公分緊湊型單體
- ✓ 承受功率：375 / 250 瓦
- ✓ 4 歐姆標準阻抗
- ✓ 鑄造鋁合金框架，結構穩固
- ✓ 黑色 Nomex 彈波設計
- ✓ 紙質振膜，呈現自然音色
- ✓ PP 防塵罩
Technical Data — RS-X 08
Material:
Cone: Paper
Spider: Nomex
Surround: Foam
Coil former: Aluminum
Basket: Aluminum
Dust Cap: PP
Specification:
Power (max / RMS): 375 / 250 Watt
DC resistance (Rdc): 3,75 Ω
Nominal impedance (ZN): 4 Ω
Resonance frequency (fs): 43,02 Hz
Voice coil diameter: 2 inch
Mechanical Q factor (Qms): 6,09
Electrical Q factor (Qes): 0,72
Total Q factor (Qts): 0,64
Moving mass (Mms): 99,39 g
Effective piston area (Sd): 216 cm²
Mechanical resistance (Rms): 4,79 kg/s
Compliance (Cms): 0,14 mm/N
Force factor (BL): 11,35 Tm
Equivalent air volume (Vas): 9,02 dm³
SPL 2,83V/1m: 88,1 dB
External diameter: 216 mm
Installation diameter: 183 mm
Installation depth: 104 mm
Magnet diameter: 126 mm
Recommended volume (sealed): 9 Liter
Recommended volume (vented): 16 Liter
